Technical Data:
| Model | RCSS8 | RCSS10 | RCSS12 |
| Output（t/h） | 6-18 | 8-24 | 10-27 |
| Carryover (bad: good) | ＞15:1 | ＞15:1 | ＞15:1 |
| Accuracy (%) | ＞99% | ＞99% | ＞99% |
| Voltage (V/Hz) | 220V/50 | 220V/50 | 220V/50 |
| Power (Kw) | 2.0-5.0 | 2.5-6.3 | 2.8-7.1 |
| Air pressure (Mpa) | 0.6-0.8 | 0.6 | 0.8 |
| Consumption (L/min) | ＜5800 | ＜8000 | ＜9600 |
| Weight (Kg) | 1350 | 1900 | 2450 |
| Dimensions (mm) | 3095*1457*1728 | 3721*1403*1926 | 4312*1403*1926 |
Rice CCD Color Sorting Machine RCSS Features:
It is equipped with the digital processing system to deliver a consistent and reliable sorting performance.
The simple and robust design of the optical sorter is designed to deliver dependable performance in the most challenging of sorting environments:
• Using high-definition color CCD camera image acquisition system, to achieve material(RGB)red, green and blue three color information acquiring, depth recognition tiny fine color sorter can choose other impurities
• Removes color defects and foreign material
• Excellent value for money
• Powerful software operation platform, easy to learn, simple and convenient to operate.
• The application of air-cooled system has solved the problems of high temperature, heavy energy loss and short service life-all of which were caused by longtime utilization of an LED light source,ensuring the durability of an LED light source under a constant temperature
• Offers simultaneous sorting, discolor sorting, reverse sorting and transparent sorting
• Dedicated after sales support available
• High-brightness and long-service-life LED light
Example of Sorting:
Packaging & Shipping
Machines to be carefully packaged to endure transportation under harsh conditions. Handling instructions are designed to protect the machine in the critical moments during transportation, unloading and installation.
Delivery Time: 20- 30 Days after order confirmed.
Payment Terms: TT, Letter of Credit.
Commissioning and Installation:
1. On Site Installation and Training Service by our professional engineer ;
2. Study and Learn the Machine Operation in Our Factory.
3. Responsive in 24 hours: Telephone, Email, Video or On Site Solutions by our Technical Experts.
After Sales Services:
• With presence in a variety of countries, Metak is strongly committed to being close to the customer.
• Through cooperation with loyal and carefully evaluated and trained local employees and partners, Metak managed to provide fast, competent and rooted services in the context of customers.
• Application center in Hefei production base offer demo machines for tests and comparison.
• A strong central technical team in Hefei is supporting local channels with training, advice and technical support.
• Under normal working circumstances, Metak machines enjoy 1 year of full warranty and a lifelong warranty on the machine structure upon the date of purchase.
• Service line is available for emergency support.
• Metak products will be serviced and supported wherever customers are located.
• Through the global Metak network and from Metak technical experts, training on Metak machines is available worldwide.
Rice Color Sorting Machine Working Video
How does the Metak Color Sorter Machine Work?
According to the different color selection of materials, detecting the colors of the granular materials that pass before them, and using mechanical or pneumatic ejection devices to divert the material whose colors do not fall within the acceptable range.
Suitable rice sorting and grading: All kinds of rice.
How Metak Color Sorter Machine Can Help you?
1. A Quality and Professional Color Sorter Supplier, Save your Money and Time.
2. Recommend a Better Solution only Meet Your Requirement: Raise the Output and Accuracy with Lower Cost.
3. Perfect After-Sale Service: On Site Installation; Engineers Training Course till You Learn; Video Instruction Guide; Response in 24 hours.
Get Your Solutions with Metak Color Sorter, Inquiry us NOW!
